EFG5K
| RECOMMENDED FOR | Extremely high-pressure, high-impulse applications such as hydrostatic transmissions. EFG6K is designed to meet or exceed all requirements of SAE 100R15 specifications and performance requirements of EN 856 4SP (-6, -8, -10 and -12), EN 856 4SH (-12, -16, and -20), and ISO 3862 Type R15 (-6, -8, -10, -12, -16, -24). Compatible with biodegradable hydraulic fluids like polyolester, polyglycol and vegetable oil as well as standard petroleum-based fluids. Available in 36 meters through 60 meters continuous lengths. |
| TUBE | Black, oil resistant, synthetic rubber (Nitrile - Type C). |
| REINFORCEMENT | Four (six for -20 and -24) alternating layers of spiraled, high-tensile steel. |
| COVER | Black, oil resistant, synthetic rubber (Neoprene - Type A), with colour coded layline. Also available with unique abrasion resistant MegaTuff® cover. |
| TEMPERATURE RANGE | -40°C to +121°C. |
| COUPLING RECOMMENDATION | -6 to -20 - GS Series - GlobalSpiral Couplings -24 to -32 - GSM - GlobalSpiral MAX One Piece Tail |
Meets Flame Resistance Acceptance Designation “MSHA 2G”. For Biodegradable Hydraulic Fluids
